BNC connector.

Also written Bayonet Neill Concelman, BNC plug, CCTV connector.

What is a BNC connector?

A BNC, bayonet Neill Concelman, is the coaxial connector that locks with a quarter turn of its bayonet ring. It is made in 50 ohm and 75 ohm builds, and analog closed circuit television runs on the 75 ohm build. Match the impedance to the cable, and choose crimp or compression termination to suit the coax in hand.

Defined by IEC 61169-8, the sectional specification for the BNC interface, published by IEC.

BNC Male Crimp RG-59, a BNC connector part supplied by Data Systems
BNC connector in the catalogue: BNC Male Crimp RG-59, DS-ICS-V2-0288-BNC-MALE-CRIMP-RG-59. Catalogue photograph.

Published by Data Systems, network material suppliers in Secunderabad, Hyderabad since 1984, which is forty years of experience with these parts. Written from the standards named above. Last checked 2026-08-14. How we check this, and what we got wrong.

Data Systems, a network material supplier in Secunderabad, Hyderabad since 1984 with branches in Vijayawada and Visakhapatnam, supplies BNC connector across India through official channels. Send a list, get one quote.

BNC Connector
